Seal Material: NBR (Nitrile Rubber)
Spool Position: 2 positions, spring offset in position b, operated in position a
Operation Type: Direct acting
Input Voltage: 24 VDC
Maximum Flow Rate: 70 L/min
Connection Type: Connector according to EN 175301-803
Solenoid Option: Standard
Mounting Type: Subplate mounting
Actuation Type: Solenoid
Product Series: Directional Control Valve
Weight: 1.5 kg
Maximum Operating Pressure: 350 bar
Maximum Operating Temperature: 60 °C
Minimum Operating Temperature: -25 °C
Seal Material: NBR (Nitrile Rubber)
For Fluid Type: Hydraulic oil according to DIN 51524
Function: 3-Way
Port Connection: NG06 / CETOP 03
Mounting Position: Unrestricted, preferably horizontal
Body Material: Cast iron
Spool Code: 020
With optimized flow passages, this valve series provides high functional limits up to 80 L/min while maintaining a very low pressure drop, resulting in energy savings. The maximum operating pressure is 350 bar.
A wide variety of spools and options allows the design of an unlimited number of hydraulic circuits. Blince Solenoid Valve offers an optional soft shift function for smooth operation. An additional orifice in the solenoid anchor dampens the shifting time.
