MCR05 Series Radial Piston Travel Motor

High Flow Radial Piston Hydraulic Oil Motor

The MCR05 Hydraulic Drive Motor is a low-speed high-torque Hydraulic Piston Motor with radial piston structure. With 380–820 ml/r displacement, 45 MPa pressure, 0–220 r/min speed, and 1510–3225 N·m rated torque, it is suitable for Hydraulic Travel Motor, Travel Motor, Slew Motor, hydraulic Slew Motor, skid steer loader, road header, construction machinery, mining machinery, and customized hydraulic drive systems.

Availability:



Inquire

Brand:
Blince

Product Description

Product Parameters

Application Scenarios

FAQ

Reliable MCR05 Series High Flow Radial Piston Hydraulic Oil Motor

The MCR05 Poclain motor is a high-performance hydraulic piston motor built for heavy-duty use. It features a advanced radial piston design for high torque and low speed. As professional motor manufacturers, we offer this China customized solution to replace standard Poclain MSE05 and MCR05 series.

This multipurpose hydraulic motor works perfectly in various mobile and industrial machines. It functions as a robust hydraulic travel motor for tracked vehicles. It also serves as a precise hydraulic slew motor for crane rotation. Our motor factory ensures every hydromotor meets strict quality standards. We are your trusted motor suppliers for high-efficiency hydraulic drive motor solutions.

Product Parameters

Feature	Technical Specification
Model	MCR05 / MSE05 Series
Motor Type	Radial Piston Hydraulic Motor
Displacement	380cc - 820cc / rev
Max. Pressure	450 Bar (45 MPa)
Max. Torque	Up to 5200 N.m
Max. Speed	0 - 300 RPM
Configuration	China Customized Shafts / Mounts
Main Use	Travel Motor / Slew Motor

Application Scenarios

Construction: The best hydraulic travel motor for mini-excavators and skid steer loaders.
Material Handling: A reliable hydraulic slew motor for truck cranes and aerial platforms.
Agriculture: High-performance hydromotor for harvesters and sprayers.
Mining: Used as a durable travel motor for underground mining equipment.
Marine: Ideal multipurpose hydraulic motor for winches and deck machinery.

FAQ

Q1: Where can I find a reliable motor factory in China that ships to the USA and Europe? A: Our motor factory is located in China but serves global markets. We are experienced motor suppliers shipping high-quality poclain motor replacements to the USA, Germany, UK, and Australia. We ensure fast shipping and local compliance.

Q2: Do you offer China customized MCR05 motors for specific regional machinery? A: Yes. We provide China customized services. We can modify port sizes and mounting flanges to fit equipment standards in your specific country. This makes our hydraulic piston motor a perfect fit for any global project.

Q3: Is the MCR05 hydraulic travel motor suitable for extreme work environments in Southeast Asia or the Middle East? A: Absolutely. Our high flow radial piston hydraulic oil motor is designed for high-temperature and high-humidity areas. Whether you need a travel motor for tropical construction or a slew motor for desert mining, our units deliver peak performance.

Q4: How do I get technical support for my hydraulic drive motor in my local time zone? A: As global motor manufacturers, we offer 24/7 technical support. Contact our sales team for data sheets or installation guides. We support clients worldwide to ensure your multipurpose hydraulic motor runs smoothly.
