The TMT V series orbital hydraulic motor is engineered for high torque output, efficiency, and durability. With a displacement of 400 cm³/rev and a 17-tooth splined shaft, this motor ensures powerful low-speed performance and long-lasting reliability across various hydraulic system applications.
Robust construction and smooth operation: The motor is built with strong housing and advanced internal design, offering stable torque delivery and excellent shock resistance. It performs reliably even in heavy-duty and demanding environments.
High efficiency and energy saving: Optimized fluid pathways reduce energy losses, improve hydraulic oil utilization, and lower operating costs. This leads to extended machine service life and reduced downtime.
Wide adaptability: Designed with a standard mounting flange (pilot Ø125 mm, BC Ø160 mm) and side ports (G 3/4, G 1/4 drain), the motor is easy to install and compatible with both open-loop and closed-loop hydraulic circuits.
Durability and reliability: Equipped with tapered roller bearings on both ends and standard NBR shaft seals, the TMT V motor maintains performance under high pressure, heavy load, and harsh environments.
Versatile applications: Ideal for use in construction machinery, agricultural equipment, forestry machinery, material handling vehicles, road maintenance machines, and municipal utility vehicles.
Basic Motor： TMT V
Displacement： 400 cm³/rev
Design Number： 0
Active： Yes
Mounting Flange： Pilot Ø125 mm, Bolt Circle Ø160 mm
Mounting Thread Dimension： None
Shaft Style： Splined shaft – 17 teeth
Shaft Size： 1 1/2 inch; M12 × 1.75 tapped hole
Shaft Key： None
Port Size/Location： Side port
Main Port Dimension： G 3/4
Drain Port Style： Standard
Drain Port Dimension： G 1/4
Brake Release Port： None
Dust Seal： Standard
Shaft Seal： NBR – Standard
Seal Kit： 151B0176
Front Bearing： Tapered roller bearing
Rear Bearing： Tapered roller bearing
Gear Wheel Set： Standard
Check Valve： No
Valve Function： Integrated flushing valve (Orifice M6 × ø1.5)
